Howo 336 Dump Truck 10 Wheel
Howo 336 Dump Truck 10 Wheel is a truck with a tipping platform that can be in a normal position and, if necessary, can be raised to unload the cargo transported therein - usually in bulk, such as sand, fertilizer, sol, etc. Using a dump truck can minimize the time for cargo transportation and unloading.
Howo 336 Dump Truck 10 Wheel consists of a car chassis, a hydraulic lifting mechanism, a power take-off and a cargo compartment. It is usually equipped with an automatic dumping device in the compartment. It usually adopts a front lift or a middle lift dumping and lifting method, which greatly saves unloading time and labor, shortens the transportation cycle, improves production efficiency, and reduces transportation costs.
In civil engineering, Howo 336 Dump Truck 10 Wheel for sale is often combined with excavators, loaders, belt conveyors, etc. to form a loading and unloading production line for loading and unloading of earth, sand, and loose materials.
Howo 336 Dump Truck 10 Wheel for sale | Howo 10 Wheeler Dump Truck Price
Specification of Howo 336hp tipper truck
Truck Model | ZZ3257N3847A |
Driving Type | RHD/LHD |
Truck Brand | SINOTRUK –HOW |
Dimension(LxWxH)(unloaded)(mm) | 8545*2496*3170 |
Cargo body size (L*W*H, mm) (mm) | 5600x2300x1500=19.32 m3, bottom:8mm, side:6m |
Lift type of Carriage | Middle Lift “F” Style |
Approaching angle/Departure angle(°) | 19/23 |
Overhang(front/rear) (mm) | 1500/1870 |
Wheel base (mm) | 3825+1350 |
Max speed(km/h) | 75 |
Dead weight(kg) | 12270 |
Gross Vehicle Weight (kg) | 25000 |
Fuel tanker capacity(L) | 300 |
Fuel type | Diesel |
Model | CNHTC Brand WD615.47, water-cooled, four-stroke,6 cylinders in line with water cooling, turbocharged and intercooled, directly injection |
Front axle | HF9, Steering with double T-cross-section beam |
Rear axle | HC16, casting axle housing, central double reduction with differential locks between axles and wheels |
Color | According to the customer’s requirements |
Cab | HW76 cab, (one sleeper, with air-condition), all-steel forward control,55ºhydraulically tiltable to the front, 2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers |
Summarize
Howo 10 wheeler dump truck price not only has efficient transportation capacity but also has safety, reliability, and durability, which can meet the needs of various working scenarios. At the same time, its user-friendly design greatly improves driving comfort. It can be described as a dump truck with excellent value for money and is also very popular among customers in the industry.
Export records of Used Dump Trucks
Transport the SINOTRUK HOWO dump truck
By flat rack, bulk cargo, or Roll-roll, You can choose the best one for delivery!
