60 Ton Side Wall Trailer
Side wall trailers are distinguished by their highly robust structural steel. We can provide cargo semi-trailers in different configurations to meet your shipping requirements.
SKU:60 Ton Side Wall Trailer
Brand: JINMA
Price:11500 USD
The Jinma 60 ton Side Wall Trailer is engineered to meet the demands of heavy cargo transportation, combining exceptional load capacity with versatile functionality. Ideal for shipping bulk materials, industrial machinery, construction equipment, and irregularly shaped goods, this trailer is a trusted solution for logistics companies seeking efficiency and reliability.
3 Axle Side Wall Semi Trailer for Sale
Technical Specifications of 60 Ton Side Wall Trailer
--Dimensions: Customizable lengths (e.g., 40ft, 48ft) with a standard height of 1.8–2.2 meters. The standard height of the guardrail is 0.6m-2m
--Frame Material: High-tensile steel with reinforced cross members.
--Suspension: Mechanical or air suspension options are available for smoother rides.
--Tires: 12R22.5 heavy-duty tires with optional anti-skid treads.
--Compliance: Meets international standards for road safety and load distribution.
60 Ton 3 Axle Drop Side Semi Trailer
Key Features of 60 Ton 3 Axle Drop Side Semi Trailer for Sale
--High-Capacity Tri-axle Design
60-ton payload capacity ensures optimal performance for heavy cargo, supported by a durable triaxle chassis with reinforced steel beams.
Equipped with wooden or steel floorboards for stable and secure cargo placement.
--Adjustable Side Wall System
Vertical-hinged side panels allow easy access for loading and unloading from both sides, reducing depot turnaround time.
Removable or foldable side walls adapt to various cargo types, from palletized goods to oversized machinery.
--Advanced Protective Coating
Multi-layer anti-corrosion treatment: A base epoxy coating with a weather-resistant acrylic topcoat ensures long-term durability.
Rustproof construction maintains structural integrity and aesthetics even in harsh environments.
--Enhanced Cargo Security
Reinforced side walls and corner posts prevent shifting during transit, safeguarding delicate or high-value shipments. Optional tarpaulin covers or steel mesh panels provide additional protection against weather and theft.
60 Ton 3 Axle Drop Side Semi Trailer for Sale | Trailer with Drop Side
Why Choose Jinma?
--Durability: Built to withstand rigorous use with minimal maintenance.
--Flexibility: Modular design supports customization for specialized cargo needs.
--Cost-Effective: Extended service life and reduced downtime maximize ROI.
Specification of 60 Ton Side Wall Trailer | |
| size | 3000x2500x3500mm |
| Payload | 60ton |
| tare weight | 10000kg |
| axle | 3x13ton/14ton/16ton/20ton brand can be opentional |
| suspension | Mechanical suspension/air suspension/American type/Germany type can be optional |
| tire | 11R22.5/12R22.5/11.00R20/12.00R20 brand can be opentional |
| wheel rim | 8.25/9.0/8.0/8.5 |
| kingpin | 2"/3.5" |
| I beam | up:14mm;bottom:16mm;middle:8mm;height:500mm;width:140mm:material:Q345B |
| landing gear | jost c200 /fuwa two speed 28ton |
| floor/side board | floor:4mm/board:3mm |
| twist lock | (opentional) |
| spare tire carrier | 2 pcs |
| tool box | 1 or more can be opentional |
| air wiring | doule air line ; |
| electricity wiring | 6 core wiring;24v or 12v ;LED lamp; |
| brake system | wabco relay valve;drum brake;t30/30 brake chamber |
| paiting | complete chassis sand blasting;electrophoresis coating;1 coat of anticorrosive prime; 2 coats of final paiting |
| cylinder | 130#/140# 5pcs/6pcs opentional |
| accessories | brake shoe;spare tire cranking;shaft head wrench;jack 50ton;tire bolt;lamp |
60 Ton Side Wall Trailer Drop Side semi Trailer
60 Ton 3 Axle Drop Side Semi Trailer for Sale
